Celestion TF0818 Pressed Chassis Low Frequency 8" 100 Watt Loudspeaker

Specialty Traders is an Authorized Celestion Dealer!

Celestion TF0818 Pressed Chassis Low Frequency 8" 100 Watt Loudspeaker

New

General Specifications

Nominal diameter203mm/8in
Power rating1100Wrms
Continuous power rating2200W
EIA power rating3150W
Nominal impedance8O
Sensitivity494dB
Frequency range70-6,000Hz
Voice coil diameter44mm/1.75in
Chassis typePressed steel
Magnet typeFerrite
Magnet weight0.88kg/31oz
Coil materialRound copper
Former materialPolyimide
Cone materialKevlar loaded paper
Surround materialCloth-sealed
SuspensionSingle
Xmax53.5mm/0.14in
Gap depth6mm/0.24in
Voice coil winding width13mm/0.51in

Small Signal Parameters
D0.17m/6.69in
Fs100Hz
Mms19.57g/0.69oz
Qms3.311
Qes0.493
Mmd15.60g/0.55oz
Qts0.429
Re6.72O
Vas9.441lt/0.33ft3
BI12.95Tm
Cms0.13mm/N
Rms3.72kg/s
Le (at 1kHz)0.75mH

Mounting Information
Overall diameter208mm/8.19in
Overall depth99mm/3.54in
Cut-out diameter183mm/7.20in
Mounting slot dimensions9.5mm x 5.5mm/0.37in x 0.22in
Number of mounting slots4
Mounting PCD range195-199mm/7.68-7.83in
Unit weight2.3kg/5.1lb
